System 2000 solid wall

Product information

One piece of innovatively milled steel becomes the foundation for limitless design possibilities. The patented mullion construction is the skeleton of this flexible, modular partition system. The wall and acoustic elements are particularly easy to install and change. Organisational elements can be hooked in to the suspension units which are included as standard. If noise insulation requirements are higher and absorbers are required for both sides, we recommend the system variant with 125 mm wall thickness. The system is rounded off by a large number of frame and door solutions.

Technical Data

  • Version: Solid wall
  • Wall thickness: 100 / 125 / 160 mm
  • Ceiling height: Up to 6 m
  • Visible width: 5 mm
  • Accessories: Absorbers, blinds, flow ducts, organisational systems

Sound insulation

Up to 44 – 53 dB Rwp (special version: 58 dB)

Fire protection

F 30 / F 90


  • Cradle to Cradle®-certified System 2000 eco
  • Excellent conversion capability and re-usability
  • Easily separable materials (dismantling, recycling)
  • Materials can be recycled after use
  • Harmless main material types: glass, aluminium, steel, wood-based materials
  • Building certificate: DGNB, LEED, BREEM; HafenCity

Picture gallery

Technical Details


Design with mullion


Solid wall, flush framed glazing, central glazing

Element types

Solid wall, balustrade, toplight, fully-glazed


Solid wall (melamine, veneered, HPL or laquered), Glass wall (toughened safety glass / acoustic laminated glass and insulating glass), Anodized / powder-coated aluminium glass frame

Wall thickness

100 / 125 mm, special version 160 mm

Visible width

Solid wall: 5 mm joint, Glass wall: frame width 2 x 25 mm / 2 x 35 mm

Sound insulation

Solid wall: bis Rwp 53 dB (special version Rwp 57 dB), Glass wall: bis Rwp 51 dB (special version Rwp 52 dB)

Fire prevention

Solid wall: various - further details upon request, Glass wall: various - further details upon request


Acoustics absorbers, blinds, climate control elements, accessory systems

Modular grid joint Solid wall
Ceiling connection Solid wall
Wall connection Solid wall
Floor connection Solid wall
